• 70L
  • Classic O-Touch design
  • 3D hot air
  • isothermal in the same layer
MASTER series of electric ovens, freer baking experience
Product Details
70L ultra-large capacity 5-layer baking trays and baking turkey weighing up to 7kg easily. The ample space allows baking with a richer imagination. Double the quantity as you desire.
3D hot air convection, more precise temperature control The unique venting design of the hot air baffle, equipped with platinum wire temperature sensor and 5 Japanese imported heating tubes, allowing more precise temperature control and more uniform temperature in the same layer
2-layer LOW-E coating glass door for thermal protection
Considerate care of every little detail for you Damping hinge
Grill/baking tray anti-drop design
Technical Parameters
  • Certification: CB/SAA/ETL/PSB
  • Product Size (mm)(W×D×H): 595X595X553
  • Built-in Size (mm)(W×D×H): Full built-in 598X598X(≥580) Half built-in 560X590X(≥550)
  • Grill+shadow Tray: grillX1+shadow trayX1
  • Door: Three layers tempered glass door(two with LOW-E coating)
  • Doorknob Material: Aluminium alloy
  • Material (oven): tempered glass
  • Control Mode: Eletronic
  • Heating Pipe: 5
  • Class A Energy Efficiency: Y
  • Power: 3.2kW(220-240V 50/60Hz)
  • Temperature Range (℃): 40-250
  • Capacity (L): 70
  • Net Weight (kg): 39
  • Gross Weight (kg): 44.5
  • Packing-Box Size (mm): 685X650X735
  • Volume (m³): 0.327
Installation Diagram
Wind tunnel installation ceiling installation diagram (unit: mm)
